Product drawing
Product parameter
High pot testing:1800VAC/1SEC/0.5mA
Shaft extension:30.5±0.5mm
No load current:0.95A
No load power:110W
No load speed:28000RPM±15%
Testing with 2020 load fan
Load current:2.90A±15%
Load power:360W
Load speed:10300RPM±300
Product parts
Production flows
● Stator production line:
Winding--Package the coil--Insert stator--Reshaping--Checking-- Dipping paint-- Drying--Checking
● Rotator production line:Stamping rotor and stator lamination-- press spider--Automatic insert rotor slot insulation-- Fit commutator--Winding-- Fusing--Insert topstick--Comprehensive test Trickling--Rough turning--Balance--Cleaning copper chips--Vision inspection
● Assembly line:Insert washer--Combination Insert screw--Vision Inspection--Insert carbon brush--Soldering Tin--FQC--Packing--OQC-- Finished motor.
Certification
Customer visiting
